| Engine |
|
|
|
| Configuration |
90 degree V twin 4 stroke, air-cooled OHV, 2 valves per cylinder. |
Lubrication |
Trochoidal gear driven pump, wet sump. 3.5 US quarts. |
| Bore & Stroke |
82.5mm x 70.2mm |
Ignition |
Distributor, points, dual coils. |
| Capacity |
748cc |
Charging system |
12v 32ah battery, 14v 19ah Bosch alternator |
| Compression Ratio |
9.8:1 (9.3:1) |
Starter |
Bosch electric starter |
| Maximum Power |
70hp (claimed) |
Transmission |
Gear driven primary drive, secondary drive via cardan shaft and double
universal joint |
| Maximum Torque |
|
Gearbox |
5 speed gearbox |
| Fuel |
30mm square slide Dell'ortos |
Clutch |
Dry two plate clutch |
|
|
|
|
| Chassis |
|
|
|
| Frame |
|
Wheels |
18 inch 40 hole alloy Borrani rims, stainless spokes. |
| Dimensions |
Weight: 539 lbs. (245kg)
Wheelbase: 1473.2mm
Length:
Ground Clearance: 11.02 inches |
Tyres |
Front 3.25 x 18
Rear 3.50 x 18 |
| Front Suspension |
Ceriani forks |
Brakes |
Front: Double drum, 220mm dia 4 leading shoe brake.
Rear: Twin leading shoe drum brake. |
| Rear suspension |
|
Fuel Capacity |
5 1/4 US Gallons |
| |
|
|
|
| Performance |
Regarded as a superbike in its day. Slow in acceleration,
but capable of maintaining very respectable speeds with remarkable economy. |
|
|
|
|
|
|
|
|
|
|
