| Engine |
|
|
|
| Configuration |
Single camshaft Desmodromic,
2 valves per cylinder, 90d Vtwin, liquid cooled. |
Lubrication |
|
| Bore & Stroke |
94 x 68 mm |
Ignition |
|
| Capacity |
944 cm3 |
Charging system |
12 V - 420 W |
| Compression Ratio |
10.2 ± 0.5:1 |
Starter |
|
| Maximum Power |
61 kW (83 CV/HP) @ 8500 r.p.m. |
Clutch |
|
| Maximum Torque |
|
Transmission |
|
| Fuel |
Alfa/n Weber electronic indirect type - CPU 1.6M, 1 injector per cylinder |
Gearbox |
1st 37/15
2nd 30/17
3rd 27/20
4th 24/22
5th 23/24
6th 24/28 |
| Inlet
Exhaust
Valves |
Open 26° B.T.D.C.
Close 72° A.B.D.C.
Open 61° B.B.D.C.
Close 34° A.T.D.C
Intake 43 mm, 11.8mm lift
Exhaust 33 mm, 11.4mm lift |
|
|
| Chassis |
|
|
|
| Frame |
|
Wheels |
MT 3,50x17"
MT 5,50x17"
Three-spoke light alloy |
| Dimensions
Weight:
Wheelbase:
Length:
Seat Height:
Ground Clearance:
|
207 kg
1430mm
2070mm
820mm
165 mm |
Tyres |
120/70 ZR 17"
170/60 ZR 17" |
| Front Suspension |
Upsidedown, fully adjustable Ø 43 mm fork, 130mm travel |
Brakes |
Front Ø320 mm
Rear Ø245 mm |
| Rear suspension |
|
Fuel Capacity |
21 Litres, 4L reserve |
|
Maximum speed 225 Km/h |
|
|
| Colour Scheme |
Black, Red or Silver |
|
|
|
|
|
|
